Stainless Steel Tube Optical Cable
Central stainless steel loose tube with steel wire armored cable
- Description of the product
F-SST self-supporting figure 8 cable contains mini F-SST as optical fiber unit and single steel wire or wire rope strengthening members. The maximun number is 24 .It is jacketed with LSZH, PE or PA. F-SST self-supporting figure 8 cable has small size and low weight. With perfect mechanical performance and wide temperature and wide temperature range, it can withstand the strong pressure and harsh environment, and is suitable for overhead laying. It is perfect solution to replace the traditional figure 8 cables.
Single mode, multimode fiber optical cable, maximum of 24 cores
F-SST
LSZH, PE, or PA jacketing, anti-ultraviolet radiation
Steel wire or wire rope strengthening
Small size and low weight
Good mechanical performance, withstanding the tensile force and force and super pressure
Waterproof, moisture-proof, anti-rodents,no rusty
Resistance to acid, alkali, salt corrsion
Outstanding high and low temperature performances
Indoor cabling
Pipe laying
Ground slot laying
Temperature sensing cable
Fire monitoring
Operating temperature: -60~+80℃
Storage temperature: -60~+80℃
Static=10D
Dynamic=20D
GYXTC8S, GYTC8S
Fiber counts
size
Cable weight
Allowable tensile force (N)
Allowing crush force (N)
d
d1
t
kg / km
Long-term / short-term
Long-term / short-term
2
1.20
1.20
1.00
31.88
1000/2000
2500/5000
4
1.35
1.35
1.00
36.62
1250/2500
2000/4000
6
1.50
1.50
1.00
44.42
1500/3000
2000/4000
8
1.75
1.75
1.00
53.37
1750/3500
2000/4000
12
2.00
2.00
1.00
57.43
1750/3500
1000/2000
